Flicker Light Spectrometer

This spectral flicker irradiance meter is a comprehensive tool for light quality and safety assessment. It goes beyond standard photometric parameters—such as CCT, CRI, Lux, Spectrum, and SDCM—to provide in-depth flicker analysis. Key metrics include Flicker Percentage, Flicker Index, Frequency, Modulation Depth, and risk assessment compliant with the IEEE Std 1789-2015 standard.

Features:
Parameters:
Wavelength range 380-780nm
Light Splitting Mode long focal cross section
Sensor High performance CCD
Spectral Bandwidth (FWHM) 2nm
Spectral Resolution 0.2nm X Y repetitive ±0.0005
Wavelength Accuracy 0.5nm
Illuminantion Accuracy (±4% Reading +1 Digital)
Lighting Area Ф10mm
Integrating Time 50μs~10000ms
CCT Range 1000K~ 100, 000K
Stray Light ≤0.3%
Illuminance Range 5lx~200, 000lx
